Adjustable Angle Hinge Connector

The Adjustable Angle Connector is one of the most versatile structural pipe fittings in the Maker Pipe building system. You can choose from two available sizes that are designed to natively fit either 3/4" or 1" EMT Conduit respectively. EMT Conduit is readily available at your local hardware store. The 1/2" connector variant includes the needed adapter shims for building with 1/2" EMT Conduit.The Adjustable Angle Connector gives you the ability to achieve any angle up to 90 degrees in either direction. Use the provided hardware to secure two pipes at a desired angle or partially tighten the top bolt and nut to create a hinge.

*Hardware is included with each Adjustable Angle Hinge Connector

Color
Silver
EMT Conduit Size
Connector

Adjustable Angle Connector Overview



Features

  • STEEL CONSTRUCTION
  • CORROSION RESISTANT E-COATING
  • PRE-APPLIED FRICTION BAND
  • POCKET FEATURE
  • INTERLOCKING PUZZLE PIECE



Description

The Adjustable Angle Connector consists of four pieces. The two long pieces secure a terminating pipe and create the end clamp. The two smaller pieces have interlocking puzzle pieces that secure a through pipe and create the puzzle piece clamp. You can buy all four pieces together or buy the bottom/top half separately if you need one and not the other.



Adjustable Angle Connector Dimensions



Made in Ameria



10 Building Tips & Tricks


See The Adjustable Angle In Action

Want to see more Maker Pipe videos?

Watch More




See It In Action




Customer Reviews

Based on 46 reviews
91%
(42)
7%
(3)
0%
(0)
0%
(0)
2%
(1)
F
Frank J. (DE)
Mini Brush Hog

There are several patches of periwinkle in my yard. They get overgrown by multiflora rose and japanese honeysuckle which are too tedious to try and uproot. So I mounted a weed trimmer on wheels, string set at about 10" high, so I can periodically cut them down and leave the periwinkle underneath. I used 1/2" EMT and a Maker Pipe kit. The EMT and fittings are definitely sturdier than PVC which did not hold up under the weight of the engine. Thanks for the idea!

S
S.J. (OK)
A few didn't hold

I ordered a couple of these adjustable angle brackets and couldn't get one of the puzzle piece parts to clamp down tight to the pipe until my boy whacked it with a mallet and sort of bent it to make it hold on. Another piece I got that goes on the end of the pipe won't tighten down either. The pipe keeps falling out of it. I find a lot of the nuts don't lock down, twisting as you try to tighten the hex bolt so that makes it hard to get them tight enough. It's a brilliant idea, and in the end I think I'll manage to make my project work, but some of the parts missed their specs.

R
Robert

Not delivered… usps is the worst! You need to provide better shipping options.

D
Daniel T.D. (AZ)
Maker Pipe used to Make a Spiral Staircase:

I was very pleased to utilize the products of Maker Pipe to conform to the handrail I designed and built for my spiral stairs. I shall show all interested a photo of the finished product. The bottom 1/2 of the handrail is 3/4" dia., while the top half is 1/2".

The handrail is very secure.

Daniel
